Product Code LKM8-S8P3-PNO-C
Connection Method M8 Connector, Threaded, 3-Wire
Number of Sockets 8
Number of Positions 3-Pos.
Supply Voltage 10 V … 30 V DC
Supply Current Max. 2 A / Socket (Totally 8 A)
Contact Insulation Resistance Max. 8 mΩ
Output Status NO
Output Type NPN
Status Display Yellow LED
Ambient Temperature -20 °C ~ 80 °C
Mounting Type Mounting on Wall or Plate
Material Socket Contact Carobronze
Nut Nickel-Plated Copper
O-Ring FKM
Potting Ethoxyline
Body Material PA66 and GF
Controller Connection 3 m PVC Cable
